ID FAN
Design Parameters

Air flow(m3/h): 191400 Inlet Static pressure(Pa): 2000

temperature(℃): 230 Medium density(kg/m3): 0.688

Our Design

Air flow(m3/h): 191400 Inlet Static pressure(Pa): 2060

temperature(℃): 86.1 Medium density(kg/m3): 145

Rotation   Air flow Total Static Efficiency Internal Needed Motor
Speed Pressure Pressure power power power
r/min No m³/h Pa Pa % Kw Kw Kw
980 1 118259 2708 2598 79.4 112 126 6Peole, 185Kw For VFD motor
2 133546 2697 2556 83.2 120 135
3 149635 2667 2490 85.7 129 145
4 164919 2598 2383 87.0 137 154
5 180206 2476 2220 86.8 143 160
6 195490 2308 2006 85.6 146 164
7 211583 2072 1718 82.8 147 165
8 226866 1800 1393 79.4 143 160
