Series no. |
6-12 series |
Feature selection |
|||||||
|
Normal |
anti-corrosion |
wear-resisting |
High temperature |
anti-explosion |
Remarks |
||||
|
Performance |
Impeller diameter |
1800-3300mm |
|
||||||
|
Rotation speed |
≤1450rpm |
|
|||||||
|
Pressure range |
2171-122597Pa |
|
|||||||
|
Flow range |
15189-703455㎥/h |
|
|||||||
|
Structure |
Blade type |
Backward, Straight, Aerofoil type |
|
||||||
|
Impeller support |
SWSI(Single Width, Single Inlet), DWDI(Double Width, Double Inlet), Overhung type |
|
|||||||
|
Lubrication method |
Oil bath lubrication, grease lubrication, lubrication oil station |
Can be specified |
|||||||
|
Cooling method |
Air cooling, Water cooling, Oil cooling |
Can be specified |
|||||||
|
Driven mode |
Direct driven, Coupling driven, Belt driven |
Can be specified |
|||||||
|
Gas composition |
Gas temperature |
Normal |
Customer request |
Customer request |
≥250℃ |
Customer request |
|
||
|
gas characteristic |
Clean gas |
Corrosive gas |
Particulate dust |
High temperature gas |
Flammable gas, explosive gas |
|
|||
|
System configuration |
Motor brand |
Chinese famous brand, ABB, Siemens, WEG etc |
Can be specified |
||||||
|
Impeller |
High quality carbon steel |
FRP, Stainless steel, Rubber Lining |
Wear-resistant layer or wear-resistant liner, ceramic patch |
High temperature high quality alloy steel |
FRP, Aluminum alloy |
Can be specified |
|||
|
Air inlet cone |
High quality carbon steel |
FRP, Stainless steel, Rubber Lining |
High quality carbon steel |
High quality carbon steel |
High quality carbon steel |
Can be specified |
|||
|
Casing |
High quality carbon steel |
FRP, Stainless steel, Rubber Lining |
High quality carbon steel |
High quality carbon steel |
High quality carbon steel |
Can be specified |
|||
|
Air damper |
High quality carbon steel |
FRP, Stainless steel, Rubber Lining |
High quality carbon steel |
High quality carbon steel |
High quality carbon steel |
Can be specified |
|||
|
Main shaft |
High strength carbon steel, Alloy structural steel |
Can be specified |
|||||||
|
Bearing |
ZWZ, SKF, FAG, NSK |
Can be specified |
|||||||
|
Bearing housing |
Cast iron |
|
|||||||
|
Foundation bolts |
GB799-1988 |
|
|||||||
|
Option parts |
System base frame, Protective screening, Silencer, Inlet & Outlet flexible connections, Inlet & Outlet counter flange, Air damper, Electric actuator, Shock absorber, Diaphragm coupling, Fluid coupling, Motor rain cover, Temperature sensor, Vibration sensor, Soft starter, Inverter, Special Electrical Motor, System monitoring Instrument. |
||||||||
