1. The aerodynamic model is used for fluid simulation, which greatly improves the design accuracy of the fan, and the efficiency of the whole machine is high.
2. The wear-resistant part of the impeller adopts surfacing welding and wear-resistant treatment to meet the airtightness requirements of the desulfurization system.
3. The key operating components are selected from well-known brands at home and abroad, which effectively improves the operation reliability of the fan products.
xThe preliminary indicator of the application environment is the industry of operation. Many industries use dust collector fans in their systems, including:
The industry application is a factor in determining what type of system and dust collector fan to select. For example, grain processing applications require a baghouse dust collector, which in turn calls for a high CFM industrial fan to enable a higher volume of airflow through the filter. Most industries use smaller, more efficient cartridge collectors, which allow for other fan options based on what kind of material the system is processing.
| serice | model | Air Capacity(m³/h) | Total Pressure(Pa) | High Efficiency(10%) | Rotation Speed(r/min) |
| 【4-10】 | No8D~29.5D | 15900~812000 | 1190~8050 | 87.1 | 730~1450 |
| No20F~31.5F | 121000~1550000 | 2140~9100 | 85.5 | 730~960 | |
| 【5-10】 | No8D~29.5D | 13740~647000 | 1540~10500 | 87 | 730~1450 |
| No20F~35.5F | 108000~1460000 | 2450~12500 | 83.1 | 730~960 | |
| 【5-12】 | No8D~30D | 10000~533445 | 1000~15000 | 85 | 730~1450 |
| No20F~35F | 100000~1024655 | 1000~15000 | 83 | 730~960 | |
| 【6-18】 | No8D~30D | 8730~621000 | 780~10790 | 86 | 730~1450 |
| No20F~35.5F | 103720~1480000 | 2805~13600 | 83.2 | 730~960 | |
| 【7-05】 | No8D~28D | 6550~401000 | 1120~12500 | 86.5 | 730~1450 |
| No20F~33.5F | 77820~1050000 | 4030~13400 | 83 | 730~960 |
1. It can output higher outlet pressure and can work in high temperature medium, suitable for any need to transport high pressure & high temperature gas industrial occasions.
2. According to customer performance requirements customized design, and optimized by CFD technology, the energy consumption is lower than similar models.
3. For the material of impeller and main spindle, we will choose high-strength carbon steel, low-alloy steel, high-temperature alloy steel, high temperature high-strength alloy steel for different working conditions temperature and working speed, so that the impeller and main spindle at high temperature still maintain reliable strength.
4. For dusty gas, we can meet all kinds of working conditions from small amount of dust to large amount of dust. After special treatment, the hardness of blade surface can reach HRC60~70, which can extend the life of the impeller by more than 3 times.
5. The moderate bonding between the components is tight, and the sealing performance is good, ensuring that the output pressure will not be reduced.
6. After annealed treatment, the internal stress of the structure generated during welding can be completely eliminated to ensure that the impeller will not creepage and crack.
7. Ultrasonic flaw detection on the welding seam and main spindle of the impeller to ensure that there are no welding defects or material defects and ensure the strength.
8. The impeller is subjected to a high standard of dynamic balancing adjusting to ensure stable operation of the fan.
9. Test assembly after production is completed to ensure that there is no interference between the components.
10. Provide on-site arrangement and guidance services.
